1. Installation Instruction Drawing
2.Electrical Characteristic
| No. | Item | Specifications | Post Environmental Tolerance | |
| 1 | Frequency（MHz） | 698~960 | 1710~2700 | |
| 2 | Gain（Zenith） | 6(max) | 8(max) | |
| 3 | Beam width-° | E:20±5 | E:10 | |
| 5 | V.S.W.R（in BW ） | ≤2.0 | ||
| 6 | Impedance | 50 Ω | — | |
| 7 | Polarization | Vertical | — | |
3. Mechanical
| No. | Item | Specification |
| 1 | Cable | RG58 5M |
| 2 | Connector | SMA |
| 3 | Plastic Housing | White |
| 4 | Size | Φ7.6×115cm |
