1.Dimension（Unit：mm）
2.Electrical Characteristics
Form 1
| No. | Item | Specifications | Post Environmental Tolerance |
| 1 | Frequency（MHz） | 855-880MHz | ±3 MHz |
| 2 | V.S.W.R（in BW ） | ≤1︰2.0 | — |
| 3 | Gain（Zenith） | 2.15dBi | ±0.5 dB |
| 4 | Polarization | Vertical | — |
| 5 | Impedance | 50 Ω | — |
| 6 | Max Power | 50W | |
| 7 | Radiation | All Directional | |
| 8 | Lightning Protection: | DC Grounding | |
| 9. | Temp | -20°~85° |
3. Mechanical
Form 2
| No. | Item | Specification |
| 1 | Cable | － |
| 2 | Connector | TNC |
| 3 | Plastic Housing | Black |
| 3 | Height | 77mm |
| 4 | Max diameter | 14.5mm |
| 5 | Min diameter | 10.5mm |
