1 Dimension（Unit：mm
2 Electrical Characteristics
Form 4
| No. | Item | Specifications |
| 1 | Frequency | 2400-2500MHz |
| 2 | V.S.W.R（5m） | ≤1.8 |
| 3 | Gain（Zenith） | 3dBi |
| 4 | Impedance | 50 Ω |
| 5 | Operating Temperature range | -30℃~60℃ |
| 6 | Max power | 40W |
| 7 | Polarization | Vertical/OMI |
| 9 | IP | IP67 |
2.2Mechanical
Form 5
| No. | Item | Specification |
| 1 | Cable | 305mm |
| 2 | Connector | IPEX |
| 3 | Plastic Housing | Black |
| 4 | Dimension | 50*48.5*13mm |
3.S Parameter Test
