1 Dimension（Unit：mm）
2. Electrical Characteristics
| No. | Item | Specifications | Post Environmental Tolerance |
| 1 | Frequency（MHz） | 2.4/5GHz | ±3 MHz |
| 2 | V.S.W.R（in BW ） | ≤1︰1.8 | — |
| 3 | Gain（Zenith） | 5dBi | ±0.5 dB |
| 4 | Polarization | Vertical | — |
| 5 | Impedance | 50 Ω | — |
| 6 | Max power | 50W | |
| 7 | Radiation | All Directional | |
| 8 | Lightning Protection: | DC Grounding |
| No. | Item | Specification |
| 1 | Cable | RG58 OR RG316 4M |
| 2 | Connector | FAKRA or others |
| 3 | Plastic Housing | Black |
| 4 | Height | 179mm |
| 5 | Max diameter | 60mm |
