1 Dimension（Unit：mm）
2.Electrical Characteristics
2.1 Dielectric Antenna
Form 1
| No. | Item | Specifications |
| 1 | Frequency（MHz） | 800-2170MHZ |
| 2 | V.S.W.R（5m） | ≤1.2.0 |
| 3 | Gain（Zenith） | 2.0db |
| 4 | Impedance | 50 Ω |
| 5 | Polarization | Vertical |
| 6 | Other Protection | IP67 UV Protected |
| 7 | Max Power | 20W |
| 8 | Temp | -30°~80° |
3.2 Mechanical
Form 2
| No. | Item | Specification |
| 1 | Connector | TNC PLUG |
| 2 | Cable | — |
| 3 | Plastic Housing | Black |
| 4 | Height | 66mm |
| 5 | Max diameter | 14.5mm |
| 6 | Min diameter | 9mm |
