1 Dimension（Unit：mm）
2.Electrical Characteristics
| No. | Item | Specifications |
| 1 | Frequency（MHz） | 800-900 MHz |
| 2 | V.S.W.R（in BW） | 1:1.5 |
| 3 | Gain（Zenith） | 6dbi |
| 4 | Polarization | Vertical |
| 5 | Impedance | 50 Ω |
| 6 | Max Power | 40W |
| 7 | Radiation | All Directional |
| 8 | Lightning Protection: | DC Grounding |
| 9 | Operating Temperature range | -40°~80° |
3.Mechanical
| No. | Item | Specification |
| 1 | Cable | RG174 3M |
| 2 | Connector | SMA |
| 3 | Plastic Housing | Black |
| 4 | Height | 310mm |
| 5 | Max diameter | 30mm |
| 6 | Min diameter | 1.5mm |
