1 Dimension（Unit：mm）
2 Electrical Characteristics
2.1 GSM Antenna
Form 1
|
No. |
Item |
Specifications |
|
1 |
Frequency（MHz） |
824～894 MHz / 1710～1990 MHz |
|
2 |
V.S.W.R（in BW） |
≤2.0︰1 |
|
3 |
Gain（Zenith） |
2 dBi |
|
4 |
Impedance |
50 Ω |
2.2 Mechanical
Form 2
|
No. |
Item |
Specification |
|
1 |
Cable |
RG 174 3m / 5m or others |
|
2 |
Connector |
SMA / MCX or others |
|
3 |
Plastic Housing |
Black |
|
4 |
Mounting |
Adhesive |
