1 Dimension (Unit: mm)
2 Electrical Characteristics
Form 1
|
No. |
Electrical Characteristics |
|
|
1 |
Working Frequency |
433 MHz ± 10 MHz |
|
2 |
S.W.R |
1.5:1 |
|
3 |
Impedance |
50 ohm (Norminal) |
|
4 |
Gain |
2.5 dBi |
| 5 |
Polarization |
Vertical |
| 6 | Admitted Power (W) | 20W |
3 Physical Characteristics
Form 2
|
No. |
Physical Characteristics |
|
|
1 |
Inner Material |
Cu |
|
2 |
Connector |
SMA Male or SMA-RP Male |
| 3 |
Operating Temp. |
-40℃～+60℃ |
| 4 |
Storage Temp. |
-50℃～+70℃ |
4 Test Report
4.1 S Parameter Test
